Product Description
Technical data
Main features
Flex Zone
Dual LightSlider: allows you to easily select and combine different cooking zones
fryingSensor Plus with 5 temperature levels
Home Connect: Program and control the device remotely via smartphone or tablet using the HomeConnect app (only in countries where Home Connect service is available).
cookConnect System: control of the hood through the induction plane electronics
5 induction cooking zones with electronic pot detector
powerMove Plus
PowerBoost function for each cooking zone
panTurbo: "turbo" function for fast heating of pans
reStart function: restore cooking settings in case of accidental switch-off
QuickStart function: enables quick selection of cooking power
End of cooking timer for each zone
Keep warm function for all cooking zones
Electronic regulation at 17 levels
Pots presence detection Safety auto switch off Child safety Temporary lock function for cleaning PowerManagement function to limit power consumption from 1kW
Energy consumption display: Display of energy consumption for each cooking cycle
Overview technical information
General
Power supply
Type of controls and indicators forward, dual lightSlider, illuminated
Key Lock safety device, time limitation, Power management function, pot detector, child safety
Highlights 17 power levels, 5 frying levels, flexInduction, fryingSensor Plus, Food Warmer Function, powerBoost
Energy consumption of hob 177,5 Wh/kg
Power consumption standby/display off mode 0.5 W
Power consumption standby/network: To deactivate the WiFi module, please refer to the user manual of the product. 2,0 W
Duration auto-standby/display mode on 20.0 min
Duration auto-standby/display off mode 20.0 min
Auto-standby/network mode duration 20.0 min
Connectivity
Home Connect
Connectivity type en: Wi-Fi
Production
Surface color black
Type of construction of the product Built in
Number of electric plates 0
Number of cooking zones 4
Type of frame Studioline
Number of gas burners 0
Number of halogen cooking zones 0
Type of installation Compact
Total number of positions that can be used simultaneously 5
Number of radiant cooking zones 0
Number of warming zones 0
Size and weight
Product dimensions (mm) 51 x 812 x 520 mm
Net weight (kg) 17.146 kg
Cooking zone 1
Cooking zone dimensions 180 mm
Location 1st cooking zone front left
Cooking zone power 1.8 kW
Type of induction heating element
Cooking zone energy consumption 175,0 Wh/kg
Cooking zone 2
Location 2nd cooking zone Cooking zone left cent.
Cooking zone 3
Dimensions 3rd cooking zone 145 mm
Location 3rd cooking zone rear left
Power 3rd cooking zone 1.4 kW
Type 3° induction cooking zone
Energy consumption 3rd cooking zone 175.0 Wh/kg
Cooking zone 4
Location 4th central rear cooking zone
Cooking zone 5
Location 5° cooking zone Rear right cooking zone
Cooking zone 6
Dimensions 6th cooking zone 400 x 210 mm
Location 6th cooking zone Cooking zone cent. right
Power 6th cooking zone 3.3 kW
Type 6° induction cooking zone
Energy consumption 6th cooking zone 185.0 Wh/kg
Cooking zone 7
Position of the 7th heating element Front right cooking zone
Cooking zone 8
Position of the 8th front central heating element
Cooking zone 9
Dimension of 9th heating element (mm) 240 mm
Position of the 9th heating element Front/centre cooking zone
Power of 9th heating element (kW) 2.2 kW
Type of 9th heating element induction
Energy consumption 9th cooking zone 175,0 Wh/kg
Security
Power indication
Residual heat indicator Separate
Key Lock safety device, time limitation, Power management function, pot detector, child safety
Main switch on/off
Link
Power cord length (cm) 110 cm
Electrical connection rating (W) 7,400 W
Power supply
Frequency (Hz) 50; 60 Hz
Accessories
Accessories included 1 x Compensation strip 750 - 780 mm
