Product Description
True Dolby Atmos® Surround Sound
Immerse yourself in theater-quality 3D sound. With two up-firing drivers, the JBL Bar 800 delivers true Dolby Atmos® 3D surround sound.
Real surround sound with detachable surround speakers
Enjoy real surround sound without the hassle of extra wires and power connections. Just place the two detachable battery-powered surround speakers behind you and get swept away in amazing audio.
BAR 800 Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in™ - Image
Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in™
Get ready to explore. Access over 300 online music streaming services through AirPlay, Alexa MRM and Chromecast built-in™. Enjoy all of your favorite audio content, Internet radio, and podcasts in high definition. The Wi-Fi connection also allows automatic software updates, so you can always enjoy the latest features.
Make movie night soar and let your music move you to new heights with 720W of total output power and thrilling bass from the 10" subwoofer. The JBL Bar 800 with Dolby Atmos® includes two up-firing drivers and detachable battery-powered surround speakers to create an immersive 3D cinema experience without having to draw extra cables. You'll never miss a word with our PureVoice technology, which makes sure dialogues are clear even when other sounds are at their loudest. And when you're ready to cut loose, stream your favorite music from AirPlay, Alexa MRM, or Chromecast built-in™. Your get-togethers will never be the same.
General Specifications
Power supply: 100 - 240V AC, ~ 50/60Hz
Networked standby power: < 2.0W
Operating temperature: 0°C - 45°C
Audio Specifications
Total speaker power output (Max @THD 1%): 720W
Soundbar output power (Max @THD 1%): 340W
Surround speaker output power (Max @THD 1%): 2x 40W
Subwoofer output power (Max. @THD 1%): 300 W
Soundbar transducer: 3x (46x90)mm racetrack drivers, 3x 0.75" (20mm) tweeters, 2x 2.75" (70mm) up-firing full-range drivers
Surround speaker transducer: 1x (46x90)mm racetrack driver
Subwoofer transducer: 10” (260mm)
Frequency response: 35Hz - 20kHz (-6dB)
Audio inputs: 1 Optical, Bluetooth, Chromecast Built-in, AirPlay and Alexa MRM, USB (USB playback is available in US version. For other versions, USB is for Service only.)
Dimensions
Total soundbar dimensions (W x H x D): 1174 x 56 x 120 mm
Main soundbar dimensions (W x H x D): 884 x 56 x 120 mm
Detachable surround speaker dimensions (each) (W x H x D): 145 x 56 x 120 mm
Subwoofer dimensions (W x H x D): 305 x 440.4 x 305 mm
Soundbar weight: 3.4 kg
Detachable surround speaker weight (each): 1.3 kg
Subwoofer weight: 10 kg
Packaging dimensions (W x H x D): 1000 x 375 x 475 mm
Packaging Weight: 18.9 kg
Control and Connection Specifications
USB port: Type A
USB rating: 5V DC, 0.5A
Supporting file format: MP3
MP3 codec: MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate: 16 - 48 kHz
MP3 bitrate: 80 - 320 kpbs
Bluetooth version: 5.0
Bluetooth profile: A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range: 2400MHz – 2483.5MHz
Bluetooth transmitter power: <15dBm (EIRP)
Wi-Fi network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range: 2412 - 2472MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 channels)
2.4G Wi-Fi transmitter power: < 20dBm (EIRP)
5G Wi-Fi transmitter frequency range
5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz
5G Wi-Fi transmitter power: 5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)
2.4G wireless transmitter frequency range: 2406 - 2474MH
2.4G wireless transmitter power: <10dBm (EIRP)
Battery
Lithium battery: 3.635V, 3283mAh
What's in The Box?
1x Main soundbar
2x Detachable wireless surround speakers
1x Wireless subwoofer
Remote control with 2 x batteries
Power cords (up to 8pcs depending on region SKUs)
1 x HDMI cable
2 x L-shape wall-mount bracket (main bar) + 2 x U-shape wall-mount bracket (for surround speakers) kit with screws
4 x Side caps
Quick start guide
Safety instruction and Warranty card
Wall mount template
